Cyclops MCP (Model Context Protocol)

Cyclops MCP allows your favorite AI agent to manage your Kubernetes applications. Cyclops MCP servers provide tools for agents to create and update existing applications safely.

This means it can check all of your existing templates and the schema of those templates to create accurate and production-ready applications. Your agent now has much less room to make a misconfiguration since it creates high-level resources (Cyclops Modules) instead of touching every line of your Kubernetes resources (Deployments, Services, and Ingresses).

It allows you to move fast and ensure no uncaught misconfigurations are hitting your production.

With Cyclops and our MCP, you can now abstract Kubernetes complexity from your developers AND your AI agents

Install

1. Make sure Cyclops is installed in your Kubernetes cluster

Check our docs on how it install it with a single command - https://cyclops-ui.com/docs/installation/install/manifest

2. Download MCP server

You can download the Cyclops MCP server binary with the following command:

GOBIN="$HOME/go/bin" go install github.com/cyclops-ui/mcp-cyclops/cmd/mcp-cyclops@latest

3. Add server configuration

⚠️ By default, Cyclops MCP will use the .kube/config file to connect to your cluster

Configure your MCP Cyclops server:

{
  "mcpServers": {
    "mcp-cyclops": {
      "command": "mcp-cyclops"
    }
  }
}

Install on a Kubernetes cluster

Instead of having each developer install mcp-cyclops binary, you can install the Cyclops MCP server with SSE as transport type to your Kubernetes cluster and allow all of your developers to connect to the same server.

1. Before installing, make sure Cyclops and all its CRDs are installed in your cluster:

   1. Check Cyclops pods are running:

      kubectl get pods -n cyclops

      Should write:

      NAME                            READY   STATUS    RESTARTS   AGE
      cyclops-ctrl-676b5d9789-ntcls   1/1     Running   0          94s
      cyclops-ui-7798655f97-xdg29     1/1     Running   0          94s

   2. Check if CRDs are installed

      kubectl get crds | grep cyclops-ui

      Should write:

      modules.cyclops-ui.com             2025-04-26T15:28:18Z
      templateauthrules.cyclops-ui.com   2025-04-26T15:28:18Z
      templatestores.cyclops-ui.com      2025-04-26T15:28:18Z

2. Install Cyclops MCP server with the following command:

   kubectl apply -f https://raw.githubusercontent.com/cyclops-ui/mcp-cyclops/refs/heads/main/install/mcp-server.yaml

3. You can now expose the cyclops-mcp service. To test your MCP server, you can port-forward it:

   kubectl port-forward svc/cyclops-mcp -n cyclops 8000:8000

4. Add your Cyclops MCP server host, or in case you are testing it, the localhost address where you port-forwarded the MCP service:

   {
     "mcpServers": {
       "mcp-cyclops": {
         "url": "http://localhost:8000/sse"
       }
     }
   }

Tools

Tool	Description
create_module	Create new Module. Before calling this tool, make sure to call get_template_schema to validate values for the given template
get_module	Fetch Module by name
list_modules	List all Cyclops Modules
update_module	Update Module by Name. Before calling this tool, make sure to call get_template_schema to validate values for the given template
get_template_schema	Returns JSON schema for the given template. Needs to be checked before calling create_module tool
get_template_store	Fetch Template Store by Name
list_template_store	List Template Stores from cluster

Configuration

You can configure Cyclops MCP server via env variables. Below is an example of adding the configuration for specifying the kubeconfig file the Cyclops MCP server should use when managing your Cyclops applications.

{
  "mcpServers": {
    "mcp-cyclops": {
      "command": "mcp-cyclops",
      "env": {
        "KUBECONFIG": "/path/to/your/kubeconfig"
      }
    }
  }
}

Environment variables

Below is the list of environment variables used for configuring your Cyclops MCP server:

Env var	Description
KUBECONFIG	Path to kubeconfig file (optional, defaults to in-cluster config or $HOME/.kube/config)
CYCLOPS_KUBE_CONTEXT	Kubernetes context to use (optional)
CYCLOPS_MODULE_NAMESPACE	Namespace where modules are stored
CYCLOPS_HELM_RELEASE_NAMESPACE	Namespace for Helm releases
CYCLOPS_MODULE_TARGET_NAMESPACE	Target namespace for modules
